A landslide volume calculation method based on LiDAR topography and slip surface reconstruction: A case study of Deda ancient landslide in Batang County of Sichuan Province
-
摘要:
由于滑坡具有突发性和运动速度快的特性，对社会和人类生命财产具有重大危害，往往滑坡体积和规模越大造成的危害也越大，因此，滑坡体积的精准计算对于防治工程的实施和防灾减灾风险评价尤为重要。目前滑坡体积计算常用的方法主要有野外测量法、几何法、数值模拟法、DEM（数字高程模型）法等，这些方法都具有一定的局限性，对于滑坡体积的计算结果精度较差。因此，提出了一种基于高精度的激光雷达（LiDAR）地形与滑动面重构的滑坡体积计算方法（LS-Drill_Volume），并以四川省巴塘县德达古滑坡为例进行滑坡体积的计算研究。通过采用机载LiDAR扫描获取德达古滑坡的地形数据；利用克里金插值法对滑坡边界点和钻孔数据进行插值，以此重构滑动面，获得滑动面高程；通过填挖方对滑坡体积进行计算，得到德达古滑坡体积为1259×104 m3，其中德达Ⅰ号滑坡体积为613×104 m3，Ⅱ号滑坡体积为646×104 m3，与野外测量法相比，体积计算精度分别提升了20.8%、21.4%和20.2%。此方法与现有体积测算方法相比，能够提供更精确的滑坡体体积，从而为滑坡评价及工程防治提供更可靠的依据。
Abstract:Because of its suddenly occurrence and rapid movement, the landslide could do great harm to the society and human life. Because the damage caused by landslide increases with the increase of landslide scale, the accurate calculation of landslide volume is extremely important for the disaster prevention and control projects, and the disaster prevention and mitigation risk evaluation. At present, the commonly used methods for landslide volume calculation mainly include field measurement method, geometric method, numerical simulation method, and DEM method, etc., but there are some certain limitations and poor accuracy of landslide volume calculation results in some of those methods. Therefore, a landslide volume calculation method was proposed, which is based on the high-precision LiDAR terrain and sliding surface reconstruction and named LS-Drill_Volume. The Deda ancient landslide, distributed in Batang County of Sichuan Province, was taken as an example for the LS-Drill_Volume study. The airborne LiDAR scanning method was used to obtain the topographic data of Deda ancient landslide, the landslide boundary points and drill data were interpolated by Kriging interpolation method, and then the sliding surface was reconstructed. Based on the obtained the elevation of the sliding surface, by means of ArcGIS software, the landslide volume was finally calculated by filling and excavation. The calculating results show that the volume of Deda ancient landslide is 1259×104 m3, of which the volume of Deda Ⅰ landslide section is 613×104 m3, and the volume of landslide Ⅱ section is 646×104 m3. Compared with the field measurement method, the volume calculation accuracy is improved by 20.8%, 21.4% and 20.2%, respectively. Compared with the existing volume measurement methods, this method can provide more accurate volume of landslide, so as to provide more reliable basis for landslide evaluation and prevention engineering.
-
Keywords:
- landslide volume /
- sliding surface /
- LiDAR /
- drill /
- Deda ancient landslide
-
致谢: 感谢审稿专家对本文提出的宝贵意见，中国地质科学院地质力学研究所金继军、宋德光硕士研究生，四川省地质调查院廖维高级工程师等参加了部分野外地质调查和数据处理工作，在此一并表示感谢。
-
![]()
图 1 四川省巴塘县德达滑坡区域位置
Q4al+pl—第四系松散堆积物；T3t1—上三叠统曲图姆沟组下段砂板岩；T3q2—上三叠统曲嘎寺组上段石英砂岩、灰岩夹基性火山岩；T3q1—上三叠统曲嘎寺组下段砂板岩、灰岩夹基性火山岩；T1-2b—中下三叠统上组砂岩、千枚状板岩夹泥质灰岩；T1-2a—中下三叠统下组千枚状板岩夹砂岩、泥沙质灰岩；γβ53—燕山期晚期斑状黑云母花岗岩
Figure 1. Location of the Deda landslide area in Batang County, Sichuan Province
![]()
图 4 填挖方体积计算原理(据参考文献[28]修改)
Figure 4. The calculation principle of fill and excavation volume
![]()
图 5 德达古滑坡DSM(A)与DEM(B)处理效果对比图
a—建筑；b—植被；a’—真实地表；b’—真实地表
Figure 5. Comparison of DSM(A) and DEM(B) treatment effects of Deda ancient landslide
![]()
图 6 德达古滑坡Ⅰ-Ⅰ'剖面工程地质图
T3q1—上三叠统曲嘎寺组下段灰岩；T1-2b—中下三叠统上组千枚状板岩
Figure 6. Engineering geological profile(Ⅰ-Ⅰ')of Deda ancient landslide
![]()
图 7 德达古滑坡Ⅱ-Ⅱ'剖面工程地质图
T3q1—上三叠统曲嘎寺组下段灰岩；T1-2b—中下三叠统上组千枚状板岩
Figure 7. Engineering geological profile(Ⅱ-Ⅱ')of Deda ancient landslide
![]()
图 9 德达古滑坡滑动面拟合结果
A—滑动面点云分布图；B—部分滑动面示意图
Figure 9. Sliding surface fitting results of the Deda ancient landslide
表 1 德达Ⅰ号滑体滑动面趋势效应
Table 1 Trend effect analysis of the sliding surface of Deda Ⅰ landslide
趋势效应 标准平均值(ME) 均方根预测误差(RMSE) 平均标准误差(ASE) 标准均方根预测误差(RMSSE) |RMSE-ASE| 无 0.60 18.67 23.02 0.83 4.35 一阶 -0.51 18.60 18.07 1.03 0.53 二阶 -0.88 19.50 18.00 1.08 1.50 三阶 -1.22 19.27 16.20 1.19 3.07
下载: 导出CSV
表 2 德达Ⅱ号滑体滑动面趋势效应
Table 2 Trend effect analysis of the sliding surface of Deda Ⅱ landslide
趋势效应 标准平均值(ME) 均方根预测误差(RMSE) 平均标准误差(ASE) 标准均方根预测误差(RMSSE) |RMSE-ASE| 无 0.33 11.83 7.88 1.58 3.95 一阶 -0.76 12.00 13.17 0.94 1.17 二阶 0.03 13.09 13.18 0.97 0.09 三阶 0.19 13.18 11.40 1.16 1.77
下载: 导出CSV
表 3 德达古滑坡体积计算结果对比
Table 3 Comparison of calculation resultsof the Deda ancient landslide
滑坡体 野外测量估算体积/104 m3 LS-Drill_Volume方法计算体积/104 m3 建议体积/104 m3 基于本文方法的计算精度提升/% Ⅰ号滑坡体 780 613 613 21.4 Ⅱ号滑坡体 810 646 646 20.2 滑坡总体积 1590 1259 1259 20.8
下载: 导出CSV
-
